understanding isofix

Understanding ISOFIX does not necessarily have to be a complex task left to Child Restraint Professionals. Understanding ISOFIX is a task every parent should see as their duty to understand and implement measures for the safe travel of their child.

What is ISOFIX

ISOFIX is a new standard for car seat installation that’s being adopted by car seat and vehicle manufacturers worldwide. The system operates through ISOFIX points on the back of the child car seat that plug onto ISOFIX fittings in the car.

In 1997, BRITAX launched ISOFIX together with VW in the Golf V. This safety system has become an international installation interface for standardised anchorage points between a child seat and a vehicle.

Only 30% of child seats are installed correctly, when using an adult seat belt, 96% of child seats are installed correctly when using the ISOFIX system!*

* Source: The German Insurance Institute GDV, Group 1

ISOFIX fittings remove the need to use the adult seat-belts to restrain the child restraint; this significantly decreases the risk of a parent installing the car-seat incorrectly.

Types of ISOFIX attachments

isofix attachments back-seatIn Australia there are two systems for ISOFIX attachment, these are RIGID ISOFIX system and the Flexible ISOFIX system.
Rigid ISOFIX Connector

Understanding Rigid ISOFIX connectors

Rigid connectors are located at the base of the child restraint, which connect to the vehicle’s ISOFIX anchorages. The top tether strap must be anchored to the vehicle. The vehicle seat-belt is not required when the rigid connectors are being used. Examples include; Britax Trufix (now discontinued) and the Nuna Pippa Klik capsule.

Flexible ISOFIX Connectors

Flexible ISOFIX connectors

Flexible straps with connectors are located at the base of the child restraint, which connect to the vehicle’s ISOFIX anchorages. The flexible connectors are then adjusted to secure the child restraint firmly to the vehicle. The top tether strap must be anchored to the vehicle. The vehicle seat-belt is not required when the flexible isofix connectors are being used.

NOTE it is illegal to use aftermarket isofix connectors, these accessories have not been tested with any seats

understanding isofix--tensioningTightness of the child restraint

Many parents will notice that when they install the ISOFIX child restraint, there is more lateral motion than normally would be with a standard seat belt installations. Provided both ISOFIX indicators are fully showing green, then you have installed the ISOFIX child restraint according to how it was meant to be installed.

It is an Urban MYTH the child restraint installation must be ROCK hard. FACT it is better to have some movement than no movement at all

Is ISOFIX any safer

ISOFIX is another attachment mechanism, preventing lateral motion. The current Australian system for Installing a child restraint is just as safe and secure as newly introduced (September 2014) ISOFIX System.

WHY Australian ISOFIX is SAFER

Many Europeans are under the misguided impression that European ISOFIX is SAFER. Here are the FACTS relating to WHY Australian ISOFIX is SAFER

ISOFIX compatible system for Australia represents a combination of changes to the Australian Design Rules for vehicles (ADR 34) and the Australian/New Zealand Standard for child restraints (AS/NZS 1754).

Australian Design Rules have been amended to set design and performance requirements for new vehicles being supplied with ISOFIX low anchorages. Vehicle manufacturers, from 1 November 2012, could voluntarily include ISOFIX low anchorages in new models of vehicles, and from 1 November 2013 for all other new vehicles of existing models.

    • Within the Australian Standard AS/NZS 1754 child restraints are required to:
  • have a top tether strap
  • have a rebound prevention feature (to keep a rearward facing child restraint in the correct position in the event of a crash)
  • be tested in a side impact (in the event of a side impact crash)
  • To be tested in an inverted position to test for occupant ejection ensuring the child does not get ejected from their child restraint should the vehicle roll over

Non Australian ISOFIX Seats – Understanding ISOFIX

Child restraints from Europe and other countries are illegal to use in Australia. These child restraints have not passed Australian standard testing, making them unsafe to use. All child restraints in Australia MUST use the top tether strap to attach to an Certified and tested anchor point in the car.

Trouble installing your ISOFIX child restraint. Contact an Accredited Child restraint Fitter in Melbourne
